รายละเอียด Reader & Writer Card
HIP Reader & Writer Card รุ่น CM69RW-B เครื่องอ่านและเขียนการ์ด ออกแบบมาให้รองรับการใช้งานกับระบบควบคุมการเข้า-ออก ระบบสมาชิก และระบบลงเวลา รองรับมาตรฐาน ISO 14443 A และ B ช่วยให้สามารถอ่านบัตรได้หลากหลายประเภท เช่น MF Classic และบัตรที่รองรับ ISO 14443-4 ได้อย่างมีประสิทธิภาพ
เหมาะสำหรับใช้งาน เครื่องอ่านและเขียนการ์ด
- ระบบลงเวลาเข้า-ออกพนักงาน
- ระบบสมาชิก (Member Card)
- ระบบควบคุมการเข้า-ออก (Access Control)
- ระบบอ่านข้อมูลบัตร Smart Card
| Model |
CM69RW-B |
| Physical Characteristics |
| Dimensions |
120.5 mm (L) x 72.0 mm (W) x 20.4 mm (H) |
| Weight |
140 g |
| Color |
Black |
| USB Host Interface |
| Protocol |
USB Keyboard Class |
| Connector Type |
Standard Type A |
| Power Source |
From USB port |
| Speed |
USB Full Speed (12 Mbps) |
| Supply Voltage |
5V |
| Supply Current |
Max. 200 mA |
| Cable Length |
2.0 m, Fixed |
| Contactless Smart Card Interface |
| Standard |
ISO 14443 A and B Parts 1-4 |
| Protocol |
ISO 14443 T=CL for ISO 14443-4-compliant cards / T=CL Emulation for MF Classic |
| Operating Frequency |
13.56 MHz |
| Operating Distance |
Up to 50 mm (depending on card type) |
| Smart Card Read/Write Speed |
106 Kbps, 212 Kbps, 424 Kbps, 848 Kbps |
| Antenna Size |
65 mm x 60 mm |
| Built-in Peripherals |
| LED |
2 single-color: Red and Green |
| Buzzer |
Monotone |
| Operating Conditions |
| Temperature |
0°C – 60°C |
| Humidity |
Max. 90% (non-condensing) |
| MTBF |
500,000 hr |
