| Camera |
| Image Sensor |
1/2.8" CMOS |
| Min. Illumination |
Color: 0.002Lux@(F1.6, AGC ON), B/W: 0Lux with IR |
| Shutter Time |
1s ~ 1/100000s |
| Day & Night |
IR-cut filter with auto switch (ICR) |
| Smart IR |
Yes |
| WDR |
120dB |
| S/N |
>42dB |
| Angle Adjustment |
0~360° (P); 0~90° (T); 0~360° (R) |
| Lens |
| Lens Type |
Fixed focal lens |
| Focal Length |
2.8mm |
| Lens Mount |
M12 |
| Aperture Range |
F1.6 |
| Aperture Type |
Fixed |
| Field of View |
100.5°(H); 56.5°(V); 113.0°(D) |
| DORI Distance |
Detect: 77m
Observe: 30.5m
Recognize: 15.5m
Identify: 7.5m
|
| Illuminator |
| IR LEDs |
2 |
| IR Distance |
Up to 50m |
| Wavelength |
850nm |
| White LEDs |
2 |
| Whitelight Distance |
15m |
| Compression Standard |
| Video Compression |
S+265 / H.265 / H.264B / H.264M / H.264H / Motion JPEG |
| Video Bit Rate |
32k ~ 16Mbps |
| Audio Compression |
G.711A / G.711U / ADPCM_D / AAC_LC |
| Audio Sampling Rate |
8kHz / 32kHz / 48kHz |
| Image |
| Max Resolution |
8MP, 3840×2160@20fps |
| Main Stream |
PAL: 20fps(3840×2160, 3072×2048), 25fps(2560×1440, 2304×1296, 1920×1080, 1280×720)
NTSC: 20fps(3840×2160, 3072×2048), 30fps(2560×1440, 2304×1296, 1920×1080, 1280×720)
|
| Sub Stream |
PAL: 25fps(704×576, 704×288, 640×360, 352×288)
NTSC: 30fps(704×480, 704×240, 640×360, 352×240)
|
| Third Stream |
PAL: 25fps(704×576, 704×288, 352×288, 640×480)
NTSC: 30fps(704×480, 704×240, 352×240, 640×480)
|
| BLC |
Yes |
| HLC |
Yes |
| 3D DNR |
Yes |
| White Balance |
Auto / Semi-Auto / Manual / Sunshine / Nature Light / Warmlight / Daylight Lamp / Filament Lamp / Lock |
| ROI |
8 rectangular static areas |
| Corridor Mode |
Yes |
| OSD |
Overlay of characters in 5 regions, max 127 chars |
| Picture Overlay |
1× BMP 200×200 (16-color) |
| Privacy Mask |
4 black static areas |
| Defog |
Yes |
| Feature |
| General Alarm |
Motion Detection; Mask Alarm |
| Exception Alarm |
Voltage / Disk Full / R/W Error / IP Conflict / MAC Conflict / Network / FTP Error |
| Linkage Method |
Email; Sound; Recording; Capture; Notify Surveillance Center |
| Video Analytics |
Human/Vehicle Classification; Tripwire; Perimeter |
| Rules of Behavior Analyse |
8 |
| Network |
| ANR |
Yes |
| Protocols |
RTSP, RTMP, HTTP(S), TCP, UDP, UPnP, SNMP v1/v2/v3, DHCP, DNS, DDNS, NTP, SMTP, TLS1.2, SSL,
802.1X, QoS, IPv4/IPv6, PPPoE, SSH, RTCP, ARP, SRTP, FTP, SFTP
|
| Compatibility |
P2P, ONVIF (S/T/G/M), SDK, CGI, Milestone |
| Remote Connection |
≤ 2 |
| Client |
Easy7 VMS |
| Mobile Client |
EasyLive Plus |
| Web |
IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+ |
| Interface |
| Communication Interface |
1× RJ-45 (10/100 Base-T) |
| Built-in Mic |
Yes |
| Reset Button |
Yes |
| On-board Storage |
microSD up to 512GB |
| RTC |
Yes |
| General |
| Web Client Language |
20 languages |
| Operating Temperature |
-35℃ ~ 65℃ |
| Operating Humidity |
≤95% RH |
| Storage Temperature |
-35℃ ~ 65℃ |
| Storage Humidity |
10% ~ 95% RH |
| Power Supply |
DC12V±25% Max 6.5W; PoE 802.3af Max 8W |
| Protection |
Surge 4000V; ESD 6000V; IP67 |
| Boundary Dimensions |
161 × 68 × 66 mm |
| Package Dimensions |
215 × 95 × 120 mm |
| Gross Weight |
0.635kg |
